Product description

• Dimmable built-in constant current LED driver
• Dimming range 5 – 100 % (min. 10 mA)
• Temperature protection as per EN 61347-2-13 C5e
• Output current adjustable between 200 – 1,050 mA via NFC, DALI or ready2mains Programmer
• Max. output power 200 W
• Up to 94.5 % efficiency
• Lowest power input on stand-by < 0.16 W
• Nominal lifetime of 100,000 h and 8 years guarantee

• Interfaces

  • Near field communication (NFC)
  • one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION)
  • ready2mains (configuration via mains)
  • U6Me2 (configuration of chronoSTEP 2 via mains)
  • Terminal blocks: 45° 0° push terminals

  • Functions

    • Adjustable output current in 1-mA-steps (NFC, DALI, ready2mains)
    • Programmable chronoSTEP: times and levels (NFC, DALI, U6Me2, ready2mains)
    • Dimming through mains voltage (inputDIM)
    • Enhanced constant light output function (eCLO)
    • Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification)
    • Configurable external temperature management (ETM)
    • Intelligent Temperature Guard (ITG)
    • Intelligent Voltage Guard Plus (IVG+)
    • Suitable for emergency escape lighting systems acc. to EN 50172

    • Benefits

      • Flexible configuration via companionSUITE (NFC, DALI, ready2mains™) or U6Me2 programmer
      • Application-oriented operating window for maximum compatibility
      • Best energy savings due to low stand-by losses and high efficiency
      • In-field programming possible after installation with NFC interface and ready2mains
      • High overvoltage protection: up to 10 kV asymmetric (protection class I and II)

      • Typical applications

        • Road, street and industry

        • 87500711		LCO 200 200-1050 355 o4a NF C EXC3
